Notifier UDACT

General
UDACT Instruction Manual PN 50050:H 09/16/2002 79
Appendix D: System 5000
General
The UDACT is capable of reporting a maximum of 120 zones when used with the System 5000. It
reports alarms and troubles on inputs and reports only troubles on outputs. Beware of 'gaps' in the
reporting of input circuits. The gaps depend upon the mounting location and FACP configuration.
AIM-200 modules are reported as a maximum of 8 zones when selecting programming entry 63=3.
Setting entry 63=4 allows point reporting of the first AIM-200 module as explained below.
For more information on the System 5000 see the System 5000 Installation Manual.
Module Slot Position
Each module slot position may accept a variety of option modules including the AIM-200, input and
output modules. Regardless of which module is placed into the module slot location, the UDACT will
report the identity of the zone/point as shown in the tables below:
AIM-200 modules placed into any module slot location must be configured as an ‘8 Zone Input’
module.
Table 26 Using AIM-200 Module Configured as 8 Zone Input Module
AIM-200 modules placed into any module slot location must be configured as an ‘8 Zone Input’
module, except the first module slot position. Program the System 5000 in ‘AIM mode’.
Table 27 Using First AIM-200 Module Configured as 192 Points
The UDACT reports by individual point the devices connected to the first AIM-200 module in the first
option module slot as follows:
Addressable Smoke Detectors 1 - 64 report as points 57 - 120.
Addressable Monitor/Control Modules 1 - 64 report as points 121 - 184
Addressable Smoke Detectors 65 - 96 report as points 185 - 216
Addressable Monitor/Control Modules 65 - 96 report as points 217 - 248
System 5000 Enclosure: Module Slot Positions
CPU Points 1 - 8 Points 9 - 16 Points 17 - 24
Points 25 - 32 Points 33 - 40 Points 40 - 48 Points 49 - 56
Points 57 - 64 Points 65 - 72 Points 73 - 80 Points 81 - 88
Points 89 - 96 Points 97 - 104 Points 105 - 112 Points 113 - 120
System 5000 Enclosure: Module Slot Positions
CPU AIM Point ID
(see below)
Points 9 - 16 Points 17 - 24
Points 25 - 32 Points 33 - 40 Points 40 - 48 Points 49 - 56
Module Slots not available in this configuration
Module Slots not available in this configuration
