3+1, 4+1 Express and 4+1 Standard Formats
38
UDACT Instruction Manual PN 50050:H 09/16/2002
Secondary Number
If '0, 2, 4, 6 or 8' are entered for address 42, the following data is automatically programmed for the
secondary phone number event codes. Enter a '0' for the data setting to disable the report. These formats
do not support zone/point programming. For zone/point reporting, refer to Contact ID.
Note: Zero entries prevent the transmission of the report to the Central Station.
Table 5 Event Codes, Secondary Number
Address Description Setting
139 Secondary # General Alarm Code 1
140 Secondary # Zone/Point Alarm Code 0
141 Secondary # General Supervisory Code 8
142 Secondary # Zone/Point Supervisory Code 0
143 Secondary # General Fault Code F
144 Secondary # AC Fault Code F
145 Secondary # Zone/Point Fault Code 0
146 Secondary # Low Battery Fault Code F
147 Secondary # Telco Primary Line Fault Code F
148 Secondary # Telco Secondary Line Fault Code F
149 Secondary # NAC Fault Code F
150 Secondary # Comm. Trouble Primary # Code F
151 Secondary # Comm. Trouble Secondary # Code F
152 Secondary # 485 Comm. Trouble Code F
153 Secondary # System Off Normal Code F
154 Secondary # UDACT Off Normal Code F
155 Secondary # General Alarm Restore Code E
156 Secondary # Zone/Point Alarm Restore Code 0
157 Secondary # General Supervisory Restore Code E
158 Secondary # Zone/Point Supervisory Restore Code 0
159 Secondary # General Fault Restore Code E
160 Secondary # AC Fault Restore Code E
161 Secondary # Zone/ Point Fault Restore Code 0
162 Secondary # Low Battery Fault Restore Code E
163 Secondary # Telco Primary Line Fault Restore Code E
164 Secondary # Telco Secondary Line Fault Restore Code E
165 Secondary # NAC Fault Restore Code E
166 Secondary # Comm.Trouble Primary Number Restore Code E
167 Secondary # Comm. Trouble Secondary Number Restore Code E
168 Secondary # 485 Comm. Trouble Restore Code E
169 Secondary # System Off Normal Restore Code E
170 Secondary # UDACT Off Normal Restore Code E
171 Secondary # System 24 Hour Test 9
172 Secondary # System 24 Hour Test w/active event F
173 Secondary # Manual Test 9
