Secondary Number 24-Hour Test Time (47-50)
This number is programmed in addresses 47-50 in the same manner as the primary number 24-Hour
Test Time. Default is 00:00 (12:00 midnight).
Secondary Number 24/12 Hour Test Time (51)
The test report sent to the Secondary phone number may be sent every 12 or 24 hours. If the report is to
be sent every 24 hours, leave the factory default entry of zero. If a 12 hour test report time is needed,
enter 1.
Start Monitoring Address (52-53)
This address is programmed to indicate the first group of zones or points to be monitored and reported
to the Central Station. See the table below.
End Monitoring Address (54-55)
This address is programmed to indicate the last group of zones or points to be monitored and reported to
the Central Station. See the table below.
Use the Start and End Monitoring Address programming locations to set the reporting range of the
UDACT.
Table 3 Start and End Monitoring Addresses
Note: For additional information on the starting and ending addresses, refer to the host FACP Manual.
ZONE REPORTING
START
(Factory Default)
Valid Entries
END
(Factory Default)
Valid Entries
AFP-100
01
2
01
01
2
01
AFP-200
01
1
01
02
1
01, 02
AFP-300/AFP-400
11
1
11 - 19
12
1
11 - 19
AFC-600, NFS-640
20
1
20 - 32
32
1
20 - 32
System 500
01
2
01
01
2
01
System 5000
01
3
01 - 04
02
3
01 - 04
System 5000 with AIM-200
01
4
01 - 04
04
4
01 - 04
NFS-3030
01
5
01 - 32 User Defined 01 - 32
Note 1. Reports status of up to 99 zones
Note 2. Reports status of up to 56 zones
Note 3. Reports status of up to 120 zones
Note 4. Reports status of up to 248 zones
Note 5. Reports status of up to 1000 zones.
POINT REPORTING
AFP-100
01
6
01
04
6
04
AFP-300/AFP-400
11
7
11 - 19
19
7
11 - 19
AFC-600, NFS-640
20
8
20 - 32
32
8
20 - 32
AM2020/AFP1010/INA,
NCA, NFS-3030
01
9
01 - 32 User Defined 01 - 32
Note 6. Reports status of up to 198 points
Note 7. Reports status of up to 448 points
Note 8. Reports status of up to 700 points
Note 9. Reports status of up to 2040 points
