Data Reporting Structure
UDACT Instruction Manual PN 50050:H 09/16/2002 59
Reporting Formats
Data Reporting Structure
The table below shows the data reporting structure for each of the pulsed formats as well as the Ademco
Express formats.
• Ademco Express formats allow a typical data message to be transmitted to the Central Station in
under 5 seconds.
• Pulsed formats typically require 15 to 20 seconds in comparison.
Table 13 on page 60 defines each letter code used in Table 12.
Table 14 on page 61 describes the data reporting structure used for Ademco Contact ID format.
Do not select any of the pulsed or Ademco Express Formats if identification of the specific zone or point
is desired. Use Ademco Contact ID for specific zone or point identification.
Table 12 Data Reporting Structure
Note: Refer to Table 17 on page 65 for a list of compatible receivers.
Format #
0, 2, 4, 6, 8
Format #
1, A, C
Report 3+1/4+1/Standard
4+1 Express
4+2/Standard
4+2 Express
Alarm SSS(S) A SSSS AA2
Alarm Restore SSS(S) RA SSSS RARA2
Zone Trouble
(Zone Open)
SSS(S) RTZ SSSS TZTZ2
Zone Trouble Restore SSS(S) RTZ SSSS RTZRTZ2
System Trouble SSS(S) TS SSSS TSTS2
System Trouble Restore SSS(S) RTS SSSS RTSRTS2
Low Battery SSS(S) L SSSS LL2
Low Battery Restore SSS(S) RL SSSS RLRL2
AC Loss SSS(S) P SSSS PP2
AC Loss Restore SSS(S) RP SSSS RPRP2
Supervisory Condition SSS(S) V SSSS VV2
Supervisory Condition
Restore
SSS(S) RV SSSS RVRV2
Test Report SSS(S) X SSSS XX2
Abnormal Test Report SSS(S) XA SSSS XAXA2
