Ademco Contact ID Format
42
UDACT Instruction Manual PN 50050:H 09/16/2002
Secondary Number
If 'E' is entered for address 42, the following data is automatically programmed for the secondary phone number
event codes. Enter a '000' for the data setting to disable the report.
Table 9 Ademco Contact ID, Secondary Number
Notes:
1) Zero entries prevent the transmission of the report to the Central Station.
2) Refer to Contact ID program locations 64 - 68.
3) The identification of the zone/device number is automatically transmitted by the UDACT and is added to the main
event code. See Table 5-3 for more information.
4) For control panels; System 500, System 5000, AFP-200, AFP-400, AFC-600, NFS-640, AFP1010, AM2020, INA,
NFS-3030, and NCA the factory default event code is 110 and reprogrammable. The AFP-400 and AFP-100 are
unique in point reporting mode in that only the control module report codes are programmable. The factory setting of
report code 111 is fixed for addressable smoke detectors and cannot be changed.
5) AFP-200 applications transmit by zone, not by point.
6) The Group # is automatically incremented for AM2020/AFP1010/INA applications.
Address Description
Setting
1
Group #
6
Sensor #
139-141 Secondary# General Alarm Code 110 00
000
2
142-144
Secondary # Zone/Point Alarm Code
5
110
4
00
Note
3
145-147 Secondary # General Supervisory Code 200 00
000
2
148-150
Secondary # Zone/Point Supervisory Code
5
200 00
Note
3
151-153 Secondary # General Fault Code 300 00
154-156 Secondary # AC Fault Code 301 00
157-159
Secondary # Zone/Point Fault Code
5
380 00
Note
3
160-162 Secondary # Low Battery Fault Code 302 00
163-165 Secondary # Telco Primary Line Fault Code 351 00
166-168 Secondary # Telco Secondary Line Fault Code 352 00
169-171 Secondary # NAC Fault Code 321 00
172-174 Secondary # Comm. Trouble Primary # Code 354 00
175-177 Secondary # Comm. Trouble Secondary # Code 354 00
178-180 Secondary # 485 Comm. Trouble Code 300 00
181-183 Secondary # System Off Normal Code 308 00
184-186 Secondary # UDACT Off Normal Code 350 00
187-189 Secondary # System 24 Hour Test 602 00
190-192 Secondary # System 24 Hour Test w/active event 608 00
193-195 Secondary # Manual Test Message 601 00
