UDACT Instruction Manual PN 50050:H 09/16/2002 87
Type Mode Programming
To disable or identify a zone or point in Type Mode (refer to "Type Mode" on page 55), the following
Entries/Addresses are used:
For Zone Identification:
Zones 1 - 99 are programmed by Entries/Addresses 01 - 99. The factory default code is 'fire alarm.'
For Point Identification:
Loop 1, Modules 101 - 196 are programmed by Type Mode Entries/Addresses 01 - 96
Loop 2 Modules 201 - 296 are programmed by Type Mode Entries/Addresses 101 - 196
Loop 1, Detectors 101 - 196 are programmed by Type Mode Entries/Addresses 201 - 296
Loop 2, Detectors 201 - 296 are programmed by Type Mode Entries/Addresses 301 - 396
System 5000 output modules are programmed by Type Mode Entries/Addresses 401 - 464
CAUTION: Addresses 97 - 100, 197 - 200, 297 - 300, and 397-400 must not be programmed. System
5000 output module addresses are dependent upon module location. Refer to the CAB-B3, CAB-C3 and
CAB-400AA illustrations on next page.
!
