Point Assignments
Use the following charts to carefully identify the function of each point in the system. Take special precaution with
any supervisory points in the system. For the UDACT to report a supervisory point to the central station, both the
FACP and the UDACT must have the point programmed as supervisory. Failure to program the panel or UDACT
correctly will result in a fire alarm signal being transmitted to the central station. All points greater than 568 can
only be transmitted as fire alarm points. Use Type Mode (
refer to "Type Mode" on page 55) to match the function
of points in the system for proper reporting.
