Data Reporting Structure
62
UDACT Instruction Manual PN 50050:H 09/16/2002
By using the Type Mode feature, identification of zone/point types is possible. Limits for the maximum
number of zones/points reported for each panel are as follows:
AFP-100 = 198 points or 56 zones
AFP-200 = 99 zones
AFP-300 = 256 points or 99 zones
AFP-400 = 448 points or 99 zones
AFC-600 = 568 points or 99 zones
NFS-640 = 568 points or 99 zones
System 500 = 56 zones
System 5000 = 120 zones
System 5000 with AIM-200 = 248 zones
AM2020/AFP1010/INA = 568 points
NFS-3030 = 568 points or 568 zones
NCA = 568 point or 99 zones
Table 15 Type Mode Reporting Codes
Type
ID #
Activated Device Report
2 Supervisory Alarm E200 00 C001
3 Pull Station Alarm E115 00 C003
4 Heat Sensor Alarm E114 00 C004
5 Waterflow Alarm E113 00 C005
6 Duct Detector Alarm E116 00 C006
7 Flame Sensor Alarm E117 00 C007
8 Smoke Zone Alarm
(Conventional)
E111 00 C002
9 Burglary E130 00 C008
A 24 Hour Non-burglary E150 00C009
B High Temperature E158 00 C010
C Low Temperature E159 00 C011
D Low Water Pressure E201 00 C012
E Low Water Level E204 00 C013
F Pump Failure E206 00 C014
