Relay Driver (Auxiliary Output) Connections
26
UDACT Instruction Manual PN 50050:H 09/16/2002
Figure 9 Monitoring for UDACT Trouble
8
9
8
8
9
9
10
11
12
13
14
150
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
0
1
2
3
4
7
6
5
TENS
ONES
DDRESS
LOOP
0
NO
ON
MR-101/C*
NC
C
18/24
115
230
+24 VDC
Comm FAILURE
EARTH
TB3
SLC from FACP
Continuation of SLC
FMM-1
UDACT
47K EOL Resistor
(included)
UDACT-05.cdr
Note: FMM-1 Monitor Module is used to supervise Normally Closed output of
MR-101/C. On UDACT trouble and Comm Fail, MR-101/C relay contact will
open causing FMM-1 to transmit trouble condition to FACP.
(MR-201/C may be used)
