NovaStar MCTRL300 User Manual

MCTRL300 Independent Controller
Specifications
3 Appearance
www.novastar.tech
2
3 Appearance
3.1 Front Panel
3.2 Rear Panel
Connector
Connector
Name
Description
Input
DVI IN

Single-link DVI connector

Resolution up to 1920×1200@60Hz and downward
compatible

Custom resolutions supported:
Resolution with maximum width: 3840×600@60Hz
Resolution with maximum height: 800×2560@60Hz
AUDIO
Audio input connector
Output
RJ45 × 2

2 Gigabit Ethernet outputs

Maximum loading capacity of a single Ethernet port:
650,000 pixels

Support redundancy between Ethernet ports.
Function
LIGHT
SENSOR
Connect to light sensor to monitor ambient brightness to
realize automatic screen brightness adjustment.
XI'AN NOVASTAR TECH CO.,LTD.

NovaStar MCTRL300 Specifications

General

Brand	NovaStar
Model	MCTRL300
Category	Controller
Language	English
