NovaStar MCTRL4K - Page 14

MCTRL4K LED Display Controller
User Manual 5 Hardware Structure
www.novastar.tech 9
2560×1600@(24/25/30/48/50/60/72/75/85/100/120)Hz
3840×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
3840×2160@(24/25/30/48/50/60)Hz
DUAL DVI-D1
DUAL DVI-D2

2 × DVI inputs, each with a maximum resolution of
3840×1080@60Hz and minimum resolution of 800×600@30Hz

Pixel capacity: 8,300,000 pixels

Custom resolutions supported:
Resolution limit with maximum width: 3840×2160@60Hz
Resolution limit with maximum height: 2160×3840@60Hz

Supported standard resolutions:
1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz
1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1200@(24/25/30/48/50/60/72/75/85/100)Hz
1920×2160@(24/25/30/48/50/60)Hz
2560×1600@(24/25/30/48/50/60)Hz
3840×1080@(24/25/30/48/50/60)Hz
3840×2160@(24/25/30)Hz
Output
1–16

16 Neutrik (NE8FBH) Gigabit Ethernet ports

Maximum loading capacity of a single Ethernet port:
− For 8-bit input sources: 650,000 pixels
− For 10-bit/12-bit input sources: 320,000 pixels

Do not support audio output.

Support redundancy between Ethernet ports.
OPT1–OPT4

10G optical ports
− Single-mode twin-core fiber: Support LC optical connectors;
wavelength: 1310 nm; transmission distance: 10 km; OS1/OS2
recommended.
− Dual-mode twin-core fiber: Support LC optical connectors;
wavelength: 850 nm; transmission distance: 300 m; OM3/OM4
recommended.

The maximum loading capacity of a single optical port equals to that
of all the 8 Ethernet ports.

4 OPT inputs/outputs
− OPT1 and OPT2 are main input/output ports. OPT1 corresponds
to Ethernet ports 1–8 and OPT2 corresponds to Ethernet ports
9–16.
− OPT3 and OPT4 are backup input/output ports. OPT3 is a
duplicate channel of OPT1, and OPT4 is a duplicate channel of
OPT2.
