NovaStar MCTRL4K - Control, GENLOCK, and Power Interfaces

MCTRL4K LED Display Controller
User Manual 5 Hardware Structure
www.novastar.tech 10
Control
ETHERNET For PC connection
USB IN Input port for cascading devices, or connecting to PC
USB OUT Output port for cascading devices
GENLOCK
IN
GENLOCK input connector

Genlock type: Blackburst

Input Genlock sync signal to ensure synchronization and same
refresh rate between the output signals of cascaded MCTRL4K units
and the external Genlock signal.
LOOP
Genlock loop output connector
Up to 10 MCTRL4K units can be cascaded.
Power
AC 100 V–240 V, 50/60Hz AC power input
Note:

Type-A USB port is prohibited from being connected to the control computer
directly.
 This product can only be worked horizontally. Wall mounting is not permitted.
