MCTRL4K LED Display Controller
User Manual 7 Menu Operations
www.novastar.tech 16
When the input source is DP, supported preset resolutions include:

1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz

1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz

1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz

1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz

1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz

1920×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz

1920×2160@(24/25/30/48/50/60/72/75/85/100/120)Hz

2560×1600@(24/25/30/48/50/60/72/75/85/100/120)Hz

3840×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz

3840×2160@(24/25/30/48/50/60)Hz
Note:
The MCTRL4K supports self-adaptation to decimal frame frequencies
(23.98/29.97/47.95/59.94/71.93/119.88 Hz).
Method 2: Custom
Set a custom width, height and refresh rate.
Step 1 Press the knob to enter the main menu.
Step 2 Choose Input Settings > Input Resolution > Custom and set the width, height and
refresh rate.
Step 3 Select Apply and press the knob to apply the settings.
Method 3: Ultra-High Resolution Settings
When the input source is DP/HDMI, you can set an ultra-high resolution via the
NVIDIA graphics card of the computer. The width or height is up to 7680 pixels.
Recommended graphics cards: NVIDIA GeForce GTX 970, NVIDIA GeForce GTX
1060, and NVIDIA GeForce GTX 750 Ti
Note:
When the width or height of the output image is greater than 4092 pixels, the
resolution must be customized only via the NVIDIA graphics card.
Step 1 Right-click on desktop.
Step 2 Select NVIDIA Control Panel.
Step 3 On the left panel, choose Display > Change resolution. On the right area, select the
controller you want to set.
