Novation Circuit User Manual

68
English
MIDI Rx (receive) and Tx (transmit) can be enabled independently for each of the data
categories. Pads 25 to 32 are arranged as four pairs of buttons as shown in the table:
Pad Function Colour
25 MIDI Note Rx on/off
Green
26 MIDI Note Tx on/off
27 MIDI CC Rx on/off
Orange
28 MIDI CC Tx on/off
29 MIDI Program Change Rx on/off
Purple
30 MIDI Program Change Tx on/off
31 MIDI Clock Rx on/off
Pale Blue
32 MIDI Clock Tx on/off
When it is shipped from the factory, both MIDI Rx and MIDI Tx are ON (buttons brightly lit) for all
data categories.
Clock settings
When Clock Rx is OFF, the clock is in internal mode and Circuit’s BPM is dened only by the
internal tempo clock. Any external clock will be ignored. When Clock Rx is ON, Circuit is in
AUTO mode and the BPM will be set by an externally applied MIDI clock at either the MIDI IN or
the USB ports if a valid one is applied; if this is not the case, Circuit will automatically switch to
its internal clock.
If Clock Tx is ON, Circuit is the clock master and its clock – whatever the source - will be
available as MIDI Clock at the rear panel USB and MIDI OUT connectors. Setting Clock Tx to
OFF will result in no clock data being transmitted.
See also “External clock” on page 57.
IMPORTANT
For any changes made to Settings View to be retained, Circuit must be powered off
by the rear panel power switch in the normal way. Disconnecting the external PSU will
result in any settings that have been changed since last power-on to be lost.

Novation Circuit Specifications

General

Type	Groovebox
Drum Tracks	4
Power	USB or 6xAA Batteries
Synth Engines	2
Pads	32 RGB Velocity-sensitive pads
Knobs	8
Effects	Delay and Reverb
Connectivity	MIDI In/Out, USB
Included Software	Ableton Live Lite, Components
Polyphony	6-voice
Sample Memory	60 seconds
Weight	1.0 kg
