Display System Utilization
en-938821/2 4 - 27
4
Erasure of tool centre path
So that subsequent movements are easier to see:
Erase the previous tool centre path
ERASE
PATH
Erasure of the part plane
So that only the tool movements are displayed:
Erase the tool centre path.
CLEAR
PLANE
Display of programme path and machine path
Two types of path can be displayed:
- programme path,
- machine path.
Select the path display type (See table below).
Type of display Softkey
Programme path
PROG.
PATH
Machine path
MACHINE
PATH
The programme path shows the change in the reference point calculated by the interpolator. This path usually
corresponds to the real path (excluding the following error).
When the real path does not correspond to the programme path (because of dynamic parameters or slaved axes, etc.),
the real path can be displayed using the axis measurement.
The following programme uses dynamic operators to perform a single axis transformation of 0.5 about the X axis and
transforms a circular path into an ellipse:
%40
N10 G00 XYZ
N20 (initialisation)
E81000=E70000-E60000/2
O1=5 E95000/E81000
N30 (transformation)
O1=2 E95000/E60000/E70000/-1
N40 (programming of the circle)
G02 XYIJ50
M02
