NUM 1050 M - Page 102

4 - 28 en-938821/2
Display of the real path as an ellipse by selecting the machine path display:
CLEAR
PLANE
ERASE
PATH
PROG.
PATH
PLANE
2
AUTO
MODE
START CYCLE
MACHINE
PATH
EXIT
X : -69.814 69.814 Y + 3.126 - 103.125
2
1
Y
X
PLANE
1
Prog %40
G02 XYIJ50
1 - Trace of plane 1
2 - Measured real path
Exit from the procedure
Return to the "GRAPHIC - PROGRAMMING" menu. ☞
EXIT
