4 - 30 en-938821/2
Moving between "TURN" and "MILL" windows
The "TURN" window is selected when the double window is displayed and the "Program", "Plane 1" field is active
(flashing).
Select the "MILL" window. ☞
WINDOW
T/M
The "MILL" window is selected and the "Program" field is active.
Use the same key to return to the "TURN" window.
Moving between fields.
Use the arrow keys to move between fields.
The active field flashes.
REMARK After selection of certain fields, new softkeys are displayed (see below).
Description of the "TURN" and "MILL" softkeys
Description of the softkeys common to the "TURN" and "MILL" windows
SCALE
T+M
TRACE
MILL
WINDOW
T/M
TRACE
TURN
EXIT
WINDOW
T/M
Key used to toggle between the "TURN" and "MILL" windows
TRACE
TURN
Key used to scale then trace the programmes whose numbers are specified in the "TURN" window (see
4.6.5.2).
TRACE
MILL
Key used to scale then trace the plane (Plane 1) and view (Plane 2 from) specified in the "MILL" window (see
4.6.5.2)
SCALE
T+M
Key used to scale all the programmes and views specified in each of the windows and define a common
scale. The "TURN" and "MILL" traces are set to the same scale.
EXIT
Return to the "GRAPHIC - PROGRAMMING" page.
Keys specific to the "TURN" window
Selecting the "Horiz" or "Vert" "Axis" field in the "TURN" window displays keys X, Y and Z on the left of the softkey bar.
These keys are used to select the axes to be scaled (see 4.6.1.1. of the Turning Operator Manual).
Keys specific to the "MILL" window
Selecting the "Plane 1" or "Plane 2 from" field in the "MILL" window displays the following keys on the left of the softkey
bar:
- "Plane 1" field: keys X-Y, Y-Z and Z-X to select the plane to be scaled
- "Plane 2 from" field: keys LEFT, RIGHT, ABOVE, BELOW to select the view of the part (see 4.6.1.1 of this manual).
