CNC Operation
en-938821/2 5 - 41
5
Actions
Select the Mode softkeys. ☞
MODE
Display of the Mode softkeys at the bottom of the screen:
SINGLE MDI DRYRUN SEARCH EDIT TEST MANUAL HOMEAUTO
Select the test mode. ☞
TEST
Display of the test mode indicator in the status window (See 3.1.3).
To monitor execution of the programme:
Select either the programme page (See 4.8) or the information page (See 4.7).
Display of the selected page.
Start the test. ☞
Display of the "INCYC" indicator in the status window (See 3.1.3).
Programme tested.
When the test has been completed, the "INCYC" indicator disappears.
Incidents
When the system detectors an error, the error indicator is displayed in the status window (See 3.1.3).
The error number, the number of the block with the error and the error message are displayed in the dialogue window
of the information, programme and current position pages, e.g.:
error 77 Block N0
Tool type not compatible with the operation
Consult the list of errors (See appendix B) and determine the cause.
Correct the programming error (See 5.4.2.2).
The error indicator disappears.
Restart the test procedure.
REMARK If the error is due to the limits having being exceeded, the error must be
acknowledged by pressing .
