CNC Operation
5
Press the
HELP
key for help on the softkeys displayed:
KERMIT transfer commands
<TRANSF> [filename]: source filename (on diskette) to be transferred
e.g.: name10.pie
<DIR> : DIR [pathname][filename]: e.g. dir \dir1 cut*.pie
displays a list of files and subdirectories in the directory
<CD..> : access the parent directory
<CD> : CD pathname]: e.g. CD dir1\dir11
directory to be accessed
<CD\> : access the root directory
<ABORT> : abort the current command.
Commands Already Described
Commands CD.., CD and CD\ are described in 5.9.5.3 and command "DIR" is described in 5.9.5.4.
Loading Part Programmes
This operation requires the presence of a formatted diskette in the drive. It is used to load into the CNC programmes
saved in a file on the diskette.
REMARK A programme with the same number as the active programme cannot be loaded
when the system is executing a cycle.
Select the directory containing the file to be loaded (See 5.9.5.3).
Select programme load. ☞
TRANSF.
Display in the dialogue window of:
Transfer>Filename: ❚
Enter the name of the file to be loaded (See syntax). ☞
Syntax
[filename].[ext]
[filename] name of the file containing the programme(s) to be loaded
[ext] extension of the file containing the programme(s) to be loaded
Display of the message:
loading part programme:
[filename].[ext]
in progress ...
When loading is complete, the dialogue line is cleared.
The programme is stored.
If several programmes are included in the file loaded, they are loaded one after the other.
