Display System Utilization
en-938821/2 4 - 25
4
Exit from the procedure
Return to the graphic display parameters page. ☞
EXIT
The 3D model of the part (and any area enlarged using the ZOOM function) is stored in memory.
Incidents
When the system detects a programming error, the 3D model calculation is interrupted and an error message is
displayed in the dialogue window.
Acknowledge the error message. ☞
Any
character
Display of the of the part whose 3D model was calculated up to the faulty block.
Analyse the causes of the error.
Exit the display pages. ☞
EXIT
EXIT
Correct the error (See 5.4.2.2) before returning to the 3D display.
Errors related to the 3D display function:
Incoherent blank definition
Display of "error 21" when the EM- and EM+ functions are incorrectly programmed.
Rewrite the block containing the EM- and EM+ functions (see 5.4.2.2).
Blank definition missing
This message is displayed when the blank has not been defined in the part programme.
Declare the blank (See 5.4.2.2) using the EM- and EM+ functions.
Display of tool not possible
The tool dimensions are too large to allow it to be modelled using the available RAM.
Modify the tool correction (See 5.2.2.2).
