TECHNICAL OWNER MANUAL
6.10 Harmony Electrical Connections
An overview of Harmony 330 and Harmony
380/380SE electrical connections is provided
below:
HARMONY ASSEMBLY OF COMPONENTS
An overview of Harmony H|Sync
electrical connections is provided below:
Y-Harness – Harmony Hub Interface to buttom bracket (bb) area
Power Harness – Battery / eBike system power to bb area
Rider Controller Cable – Handlebar to BB area
Connection to eBike power (OEM to provide)
Harmony connections (provided)
18-44V
H|Sync Harness – Connects directly to eBike system for power and CAN communication
H|Sync connections (provided)
