TECHNICAL OWNER MANUAL

8. Harmony technical data

HARMONY TECHNICAL DATA

8.1 CVP Speciﬁcations

*Harmony Hub Interfaces

MY12-15 are chain

compatible only

**This data refers to all

Harmony Hub Interfaces

MY12-15 which are chain

compatible only

Hub N330

Hub colors Silver or black

Speed ratio Inﬁnitely variable within ratio range

Ratio range 330% nominal, 0.5 underdrive to 1.65 overdrive

Controller H3

Other compatible controller –

Shifting Variable twist grip, ¾ turn

Hub Interface HHI3

Other compatible HI‘s –

Spoke conﬁgurations 32 or 36 hole

Brake conﬁgurations Disc, rim, or roller

CVP weight 2450 grams

Drop-out width 135mm, horizontal or vertical

Axle length 183mm

Axle threads M10 x 1

Chainline 49.0 ± 0.5mm

Beltline (Gates) 45.5 ± 0.5 mm

Beltline (Conti-Tech) 46.2 ± 0.5 mm

Sprocket sizes 16-22 tooth (chain)

20-28 tooth (belt)

Sprocket type Standard 9-spline, ﬂat on one side

Sprocket ratio deﬁnition Front sprocket teeth / Rear sprocket teeth

Sprocket ratio minimum (Pedal bikes) 1.8 (Table in section 8.2)

Sprocket ratio minimum (Front motor e-Bikes) 1.8 (Table in section 8.2)

Sprocket ratio minimum (Mid motor e-Bikes) 2.1 (Table in section 8.2)

Spoke ﬂange diameter 125.0 mm

Center to left spoke ﬂange 26.0 mm

Center to right spoke ﬂange 26.0 mm

Harmony 330

Hub N380/N380SE

Hub colors Silver or black

Speed ratio Inﬁnitely variable within ratio range

Ratio range 380% nominal, 0.5 underdrive to 1.9 overdrive

Controller H8

Other compatible controller H|Sync
