NuVinci Harmony H|Sync - CVP & Harmony Shifter Dimension

26
EN
TECHNICAL OWNER MANUAL
8.4 CVP & Harmony Shifter Dimensions
HARMONY TECHNICAL DATA
H3 controller H8 controller
CVP with Harmony Hub Interface CVP with Harmony Hub Interface Harmony Hub Interface
125
32 AND 36 SPOKE
CONFIGURATIONS
AVAILABLE
2.9
SPOKE
HOLE
SCALE 0.500
SCALE 0.500
183 AXLE WIDTH
135 DROPOUT WIDTH
VERSION
DISC BRAKE
ISO 6 BOLT
16.0
41
73
67.5
CENTERLINE
49.0
CHAINLINE
26.026.0
MULTI-GEAR
(2.3MM OR 3/32")
CHAINS AND
SPROCKETS ONLY
