12. List of figures
Fig 1. LPCXpresso546x8/540xx/54S0xx underside
view ................................................................... 4
Fig 2. LPCXpresso546x8/540xx/54S0xx main feature
layout ................................................................ 6
Fig 3. Jumper and LED locations ................................ 7
Fig 4. Identifying the VCOM port ............................... 18
Fig 5. Current measurement circuit error .................. 21
Fig 6. Line input circuitry ........................................... 28
Fig 7. Headphone / line output circuitry ..................... 28
Fig 8. CAN-FD Shield Layout .................................... 30
