NXP Semiconductors

UM11035

LPCXpresso boards for LPC546xx/LPC540xx/LPC54S0xx families of

MCUs

UM11035

All information provided in this document is subject to legal disclaimers.

User manual

Rev. 2.1 — 7th January 2019

13 of 36

Circuit Ref

Description

Section

J14

Host/peripheral expansion connector

0.1” pitch 2x6 connector for host connection / expansion. This connector

is primarily intended for connection and external host using I

C and/or

SPI bus, but is also suitable for general purpose I/O connections or

peripherals.

7.3

J15

Host reset control

This connector provides a reset input to the LPC546x8/540xx/54S0xx

along with ground signals.

7.3

J16, J17

LCD and touch screen display connectors

These connectors are dedicated for the LCD and touch screen. On

boards with an LCD already installed, they are located under the LCD

panel and should not be handled by the user unless instructed to do so

by NXP. For boards without an LCD installed, use these connectors to

attach the optional LCD panel.

n/a

3. Getting Started

The LPCXpresso54608 and LPCXpresso54628 boards are pre-programmed with a demo

application showcasing Embedded Wizard from TARA Systems (note that some older

stock may contain a demonstration from a different vendor). Connect a micro USB cable

from connector J8 or J1 to a power source (computer or power supply) and the board will

boot within a few seconds and run this demonstration.

The LPCXpresso54618 board, as supplied in the OM13094 CAN-FD kit, is pre-

programmed with a CAN loopback example. For more information on this example

please refer to Section 10.

The LPCXpresso54018 board is pre-programmed with a demo application using emWIN

graphics. Connect a micro USB cable from connector J8 or J1 to a power source

(computer or power supply) and the board will boot within a few seconds and then run

this demonstration. The LPCXpresso54018 demo is the “touch and draw” emWIN

example from the SDK.

The LPCXpresso54S018 board is pre-programmed with a spirit level demonstration

program, which uses the User LEDs and on-board accelerometer. Connect a micro USB

cable from connector J8 or J1 to a power source (computer or power supply), Place the

board on a flat surface, and the 3 User LEDs will all light; tilting the board (rotating about

the axis of the horizontal center of the board) will cause the LED pattern to change to

illustrate the angle of tilt.

For further information on Embedded Wizard and to load free evaluation version of their

tools for these boards, please visit the TARA systems website at https://tara-systems.de/

This section also describes how to download pre-built binary images to the

LPCXpresso546x8 boards using its mass storage device capability, and how to set up

the board to start debugging sessions using popular development tools. Note that the

mass storage boot mode does not program off-chip flash devices (such as the quad SPI

flash on the board), so some application examples (such as the Embedded Wizard

demos) will require a different utility (J-flasher lite from SEGGER, MCUXpresso IDE’s
