(Note: Although not required for the HS USB port operation, it is recommended to check
JP11, JP12 and JP13 have a jumper in position 1-2 to enable Ethernet operation and
availability of the I/O at the Expansion connector D8.)
7.3 Host Expansion Header (J14)
This header provides connectivity from the LPC546x8/540xx/54S0xx target to a remote
Host, peripherals or other devices. Table 4 shows the connections.
Table 4. Host Expansion Header signals
Pin
J14 signal
Flexcomm # / Port
1
GPIO/SPI-SSEL in/out
3 / PIO0-1
2
GPIO/SPI-MOSI in/out
3 / PIO0-3
3
GPIO/SPI-MISO out/in
3 / PIO0-2
4
GPIO/SPI-SCK in/out
3 / PIO0-0
5
GND
6
VDD (3.3V)
7
GPIO/INT (out/in)
PIO0-5 (default) or PIO0-4, set by JS32
8
GPIO/RESET (out)
PIO3-13
9
SCL
1 / PIO0-14 Rev C and earlier
1 / PIO0-13 Rev D and later
10
SDA
1 / PIO0-13 Rev C and earlier
1 / PIO0-14 Rev D and later
11
GND
12
VDD (3.3V)
This connector shares SPI interface signal connections with the SPI bridge function (i.e.
connection from the LPC546x8/540xx/54S0xx to the Link2 Debug Probe); only one of
these functions may be used at once. By default jumper JP6 is open, connection the
Flexcomm 3 SPI port to the Link2 device; install JP6 if using the SPI port on J14.
By default, solder jumpers JS15 and JS16 connect the LPC546x8/540xx/54S0xx
Flexcomm 1 I
2
C port to the Link2 device; these may be removed if they will interfere with
other devices interfaced to J14. Note there are 2.2KΩ pull-up resistors to 3.3V for these
SDA and SCL connections.
7.4 PMod Slave Expansion Header
This header provides connectivity from the LPC546x8/540xx/54S0xx target to PMod
peripherals or other devices. Table 5 shows the connections.
Table 5. PMod Slave Expansion Header signals
Pin
PMod standard connection
J11 signal
Flexcomm # / Port
1
GPIO/SPI-SSEL out / UART CTS in
GPIO/SPI-SSEL in/out
9 / PIO4-6 (default) or
PIO3-30, set by JS27
