20 Océ 3050 User Manual
viewing (browsing) after drawings have been scanned. The different display
modes are described in detail in
‘Choosing a display mode’ on page 34.
Utilities This pull down menu provides the Configuration and Clean Drum
options. The Configuration option is described in
‘Configuration’ on page 78.
Clean Drum is described in ‘Cleaning the drum’ on page 92.
View This is a pull down menu allows you to view a selected image data file.
The Viewing mode is described in chapter 4.
Help The Help option provides on-line context sensitive help on all aspects of
the system operation. Clicking the Help option during operation will display
information concerning the process (this option is not available below version
3.1).
The selection buttons
There are four main selection buttons which are placed at the top of the Control
window. Each of these opens a setup dialogue box.
[7] The selection buttons
Scanner setup Clicking the Scanner Setup button brings up the Scanner Setup
window. It provides all the setup tools related to the scanner. You can find more
information in
‘The scanner setup’ on page 44.
Printer setup Clicking the Printer Setup button brings up the Printer Setup
window. It provides all the setup tools related to the printers. You can find more
information in section
‘The printer setup’ on page 72.
File Handling Clicking the File Handling button brings up the File Setup
window. It allows setting up the details of the output files, file naming etc.
More information is in
‘The file handling setup’ on page 82.
Job Management Clicking the Job Management button brings up the Job
Management window. It allows setting up the log file and file size limits for the
job. More information is in
‘The Job Management Menu’ on page 85.
