Oceanic PROPLUS X - 4: TLBG (TISSUE LOADING BAR GRAPH); 5: DTR (DIVE TIME REMAINING); 6: TURN PRESS

28
PROPLUS X OPERATING MANUAL
© Pelagic, 2016 Doc. No. 12-5655-r01 (8/19/16)
4: TLBG (TISSUE LOADING BAR GRAPH)
This feature allows you to set an alarm to go off at a predetermined percentage of Tissue Loading Bar Graph being lled.
AUDIBLE
DEPTH
EDT
TLBG
DTR
TURN PRESS
LOW PRESS
SET
TLBG ALARM
80 %
(<) BACK TO MENU
VALUE
^
- INCREASE
v - DECREASE
> - SAVE
CONTROLS
increase value
decrease value
to Alarms Set Menu
to save value
AR
%
0
GAS 1
-AIR
FO2
PO2
-
81
FT
11
NDC
54
TL
%
1139
PSI
(v) TO MENU - (>) TO COMPASS
38
EDT
25
GTR
NITROGEN
TLBG Alarm Triggered
5: DTR (DIVE TIME REMAINING)
The Dive Time Remaining Alarm allows you to set an alarm to go off with a designated reserve. Settings include OFF or 5 - 20 min of dive
time remaining.
AUDIBLE
DEPTH
EDT
TLBG
DTR
TURN PRESS
LOW PRESS
SET
DTR ALARM
(<) BACK TO MENU
5 min
VALUE
^ - INCREASE
v - DECREASE
> - SAVE
CONTROLS
increase value
decrease value
to Alarms Set Menu
to save value
AR
%
0
GAS 1
-AIR
FO2
PO2
-
12
37
FT
NDC
54
TL
%
1031
PSI
(v) TO M ENU - (>) TO COMPASS
50
21
EDT
GTR
DIVE TIME
DTR Alarm Triggered
6: TURN PRESS
The Turn Pressure Alarm allows you to set an alarm to go off at a designated turn pressure. You may choose from OFF or 1000 to 3000
PSI (70 to 205 BAR) in increments of 250 PSI (5 BAR).
AUDIBLE
DEPTH
EDT
TLBG
DTR
TURN PRESS
LOW PRESS
SET
TURN PRESS ALARM
(<) B ACK TO MENU
VALUE
^ - INCREASE
v - DECREASE
> - SAVE
1500 PSI
CONTROLS
increase value
decrease value
to Alarms Set Menu
to save value
AR
%
44
GAS 1
-AIR
FO2
PO2
-
11
81
FT
NDC
54
TL
%
1500
PSI
(v) TO M ENU - (>) TO COMPASS
38
EDT
15
TURN PSI
GTR
Turn Press Alarm Triggered
