Oceanic PROPLUS X - BUTTONS

9
PROPLUS X OPERATING MANUAL
© Pelagic, 2016 Doc. No. 12-5655-r01 (8/19/16)
GAS 1
-AIR
FO2
PO2
-
SURF
:
23 59
NORM
74°F
12:36
PM
70%
0
TL
%
3000
PSI
S1A
(v) TO MENU - (>) TO COMPASS
0
DIVE
--
GTR
BUTTONS
The ProPlus X utilizes 4 control buttons Up, Down, Left, and Right. They allow you to select mode options and access specic information. They are
also used to enter settings and acknowledge the audible alarm.
Pressing different combinations of these buttons will navigate through different menus and options of the ProPlus X. In some instances the buttons
need to be pressed longer. The symbols below will be used throughout this manual to illustrate whether the button needs a short or long press.
SYMBOL MEANING
PRESS BUTTON LESS THAN 2 SECONDS
HOLD BUTTON GREATER THAN 2 SECONDS
