ODB LCT6000 - Exhuast Duct Assembly

102
ODB COMPANY
800-446-9823 LCT6000
LCT6000 after February 2001
#5,#6 and #7 do not come as standard equipment
To mount #5, Item #6 is required for all units built after Feb. 2001
18" DIAMETER
(STANDARD)
*16" DIAMETER
(OPTIONAL)
ITEM # PART NUMBER PART NUMBER DESCRIPTION
1
LCT631.610 LCT621.610 Discharge Duct
2
LCT631.611A
LCT631.611
LCT630.629
LCT621.611A
Transition, 49" Long(18"),61"L(16")
Transition, 43" Long(18"),43"L(16")
3
LCT616.618 LCT616.616 Hose Band
4
LC-MDH.18.72 LC-MDH.16.48 Exhaust Hose,5'L(18"), 4'L(16")
5
LCT60.629B LCT60.629A Exhaust Hose Support (OPTIONAL)
6
**LCT60.629BCL **LCT60.629BCL Hose Support Clamp (OPTIONAL)
7
N/A LCT631.621 18" to 16" Rectangular Transition
*Note: the 16" column is for 6000 units that have a 16" diameter exhaust only.
**Note: Item #6 ts 6" x 4" (6000) tow bars only.
1
7
2
3
4
5
6
8.5 Exhuast Duct Assembly
