114
ODB COMPANY
800-446-9823 LCT6000
10.3 M3219 Hydraulic Boom Pump
ITEM # PART NUMBER DESCRIPTION
MP-M3219.S Complete Pump Assembly (all above)
1
MP-08004 Electric Motor, 12V
2
MP-17744 Solenoid Switch, heavy duty
3
MP-19283D Coil, Cartridge Assembly
4
MP-07193.D Cartridge
5
MP-10861.D Coil, 2 way - 2 position
6
MP-06232 Plastic Reservoir, 3.5" x 15.7"
2
1
6
5
4
3
