34
ODB COMPANY
800-446-9823 LCT6000
Operating Section
3.3 Engine Controller-Operating Cont.
Engine must undergo a 60 deg warmup before clutch switch is live (active/useable)
Must Engage AND Disengage UNDER 1300rpms, anything over 1300 will not engage or
disengage
Menu Navigation
1) Press MENU button to scroll available menus
2) Press UP button to enter into a menu
3) Press DOWN button to exit a menu
Change a Menu Setting (Controller Setup menu)
1) A password is required to change a setting
2) Press ENTER button (A bracket appears around the setting)
3) Press the UP and DOWN buttons to view available selections
4) Press ENTER button to make selection, (brackets disappear)
5) Exit menus (hold down MENU button and simultaneously press the ENTER button)
6) RECYCLE POWER TO THE PANEL (Turn panel power off and then back on)
