ODB LCT6000 - Trailer Bed Group

104
ODB COMPANY
800-446-9823 LCT6000
9.1 Trailer Bed Group
LCT6000
ITEM# PART NO. DESCRIPTION
1 SCL822.619A Tire and Rim Assembly
consists of:
.SCL822.619.T2 Tire only
.SCL822.619.R Rim only
2 LCT622.602.L Battery Box Latch
3 LCT622.604 Battery Box Door
4 LCT630.601B Fender, RH
5 LCT630.602B Fender, LH
6 LCT622.601.09 Trailer Bed, 600
LCT630.630.05 Trailer Bed, 6000
7 LCT622.614TE Axle Assembly, 600
6000.12 Axle Assembly, 6000
ITEM# PART NO. DESCRIPTION
8 STD.2414 Tail Light Assembly
9 OD-60250R LED Light only
10 OD-60700 Grommett
11 OD-94706 Plug Harness
12 STD.2201 LED Market Light, Yellow
13 STD.2201G Grommett, marker light
14 STD.2202 LED Marker Light, Red
15 600.2437 License Plate Mount Brkt
16 LCT600.010 License Plate Bracket
17 LCT60.615B Licesne Plate Light
6
7
1
1
1414
1313
5
1111
1010
99
8
15
16
17
1212
1313
1313
1212
4
1313
3
2
14
14
