90
ODB COMPANY
800-446-9823 LCT6000
7.2 AutoHD PTO Assembly Group
February 2006 - Present
The AutoHD end cap is 6-sided, the older Auto is round. They are
not interchangeable! Some units in the time period above used the
standard Auto PTO. Please verify.
ITEM # PART NUMBER DESCRIPTION
*
OD-41500252 Complete PTO Assembly (items 1 -11,13)
**
OD-48080050.8OF **Complete PTO & Clutch Assembly
1
OD-45000212 Bolt, 5/16-18 x 1-1/4" HD model
2
OD-41500205M Bearing Retainer Cover
3
OD-41500206 PTO Bearing, Rear
4
OD-LCT650.601K
OD-LCT650.601F
Key, Stepdown--direct drive units only
Key, belt drive units only
5
OD-41500203 PTO shaft
6
OD-45000105 Bolt, 9/16-12 x 1- 3/4"
7
OD-45000177 Bolt, 9/16-12 x 3"
8
OD-45000103 Lock Washer, 9/16"
9
OD-41500204 PTO Housing
10
OD-41500242 PTO Collar, 03/08 - present
11
OD-41500207 PTO Bearing, Front
To Next Page
