Oki B4350 Service Manual

42641101TH Rev.1 155 /
Oki Data CONFIDENTIAL
Table 6-2 2nd Tray Parts List
No. Description OKI Parts No. Q'ty/U
Plate, upper
Sheet guide assembly
Front cover assembly
Inner guide assembly
Cassette assembly (2nd tray)
Separation frame assembly
Cover, rear
Stick finger
Hopping flame assembly
Bush, metal (ADF)
Gear (z70)
Lever, sensor (p)
Feed roller assembly
Cable & connector
Stepping motor
Bracket
Gear (z24)
Gear (z87/z60)
Plate, bottom
2nd cassette guide (L) assy
Hopping roller assembly
2nd cassette guide (R) assy
One-way clutch gear
Board GRT
Spring, Tension
Lever, sensor (T)
DIN8P-DIN8P Connector Cord
Connection Cord
Spring-Release
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
2
500
3
3
3
3
3
6
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
6
3
3
3
3
3
6
1000
5
5
5
5
6
12
5
5
6
5
5
5
5
5
6
5
5
5
5
6
6
6
12
6
6
6
6
6
12
1PP4122-1401P001
3PA4122-1370G001
1PA4122-1369G001*
3PA4122-1371G001
50107304
53345801
1PP4122-1323P001
4PB4122-1441P001
1PA4122-1366G001
4PP3522-3568P001
4PP4122-1207P001
3PP4122-1331P001
50222501
3YS4111-3528P001
56512201
4PP4122-1384G001
4PP4122-1383P001
4PP4122-1226P001
2PP4122-1389P001
1PA4122-1365G001
50409501
42337801
51401101
42372702
41804801
42372601
42372601
40890502
41204801
* For the rev. no. of the Parts List for the Front cover assembly should be applied No.6.
The No.6 includes a change of Release spring [P152, No.29]
** For the rev. no. of the Parts List for the Cassette assembly (2nd tray) should be applied No.10.
The No.10 includes a change of cassette and Tale Guide.
Addition of notch
Addition of groove
Cassette
Addition of projection part
Addition of latch
Tale Guide
Note : Cassette and Tale Guide need concurrent replacing.

Oki B4350 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	6.2 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Internal memory	16 MB
Processor model	Power PC
Built-in processor	Yes
Maximum internal memory	272 MB
Sound power level (standby)	38 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Paper tray 2 input capacity	500 sheets
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power requirements	230VAC + / - 10%
Compatible operating systems	-Windows 95/98/98 SE/ME/NT4 Workstation/NT4 Server/2000 Workstation/2000 Professional/2000 Server/2000 Advanced Server/XP Professional/XP Home/NT Terminal Server Edition/2000 Terminal Server. -Mac OS 8.6/OS X 10.1.
Display	LCD
Maximum duty cycle	30000 pages per month
Power consumption (printing)	350 W
Power consumption (PowerSave)	13 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	355 x 395 x 200 mm
