42641101TH Rev.1 7 /
Oki Data CONFIDENTIAL
1. CONFIGURATION
1.1 System Configuration
B4350 consists of control and engine blocks in the standard configuration, as shown in Figure 1-1.
In addition, the options marked with asterisk(*) are available.
Figure 1-1
Operator Panel
LCD : 1
LED : 1
SW : 8
Drum Motor
Paper
Cassette
ID
Unit
Paper Feeding
Mechanism
(First Tray Unit)
Registration
Motor
Hopping Motor
LED Head
Electrophotogarphic
Processing Unit
Fuser Unit
Halogen-Lamp
High Voltage /
Sensor Board
ROM DIMM
*
High Capacity
Second Paper
Feeder
*
Multi Purpose
Feeder
IEEE1284
USB
Network
RS232C
*
Network
Board
OR
*
RS232C
Board
*
* : Optional
AC
INPUT
Power Supply
Board
Face Down
Stacker
FAN
RAM
DIMM
*
Main Control Board
