42641101TH Rev.1 8 /
Oki Data CONFIDENTIAL
1.2 Printer Configuration
The printer unit consists of the following hardware components:
• Electrophotographic Processor
• Paper Feeder
• Controller
• Operator Panel
• Power Supply Unit
The printer unit configuration is shown in Figure 1-2.
Figure 1-2
Upper cover
Operator panel assy
Stacker assy
Optional board
Legal/universal paper cassette
Image drum unit(Type 9)
(consumable)
Toner-cartridge(Type 9)
(consumable)
Power supply
High Voltage / Sensor board
Main control board
