Oki B4350 Service Manual

42641101TH Rev.1 45 /
Oki Data CONFIDENTIAL
3. ADJUSTMENT
This chapter provides explanations concerning the adjustment necessary when replacing a part. The
adjustment is made by changing the parameter value set in EEPROM on the main control board. The
parameter can be set by the key operation from the operator panel. This printer has three kinds of
maintenance modes, and it is necessary to select one of the modes when replacing any parts.
3.1 Maintenance Modes and Functions
3.1.1 User Maintenance Mode (Administrator Menu)
In order to enter Admin MENU, turn the printer on while holding down the ITEM+/ITEM- switch.
Function
There are seventeen functions as follows:
Functions
Sets All Category Enable/Disable of User Menu.
Set to Disable, User Menu is not shown. Subsequent Items are
not displayed if the Categories are disabled. Panel Lock is
available when this MENU is set to DISABLE.
Sets Category INFORMATION MENU Enable/Disable.
Set to Disable, Category INFORMATION MENU of User Menu is
not displayed.
Sets Category PRINT MENU Enable/Disable.
Sets to Disable, Category PRINT MENU of User Menu is not
displayed.
Sets Category MEDIA MENU Enable/Disable.
Sets to Disable, Category MEDIA MENU of User Menu is not
displayed.
Sets Category SYSTEM CONFIG MENU Enable/Disable.
Set to Disable, Category SYSTEM CONFIG MENU of User Menu is
not displayed.
Sets Category PCL EMULATION MENU Enable/Disable.
Set to Disable, PCL EMULATION MENU of User Menu is not
displayed.
Sets Category PPR EMULATION MENU Enable/Disable.
Set to Disable, PPR EMULATION MENU of User Menu is not
displayed.
Sets Category FX EMULATION MENU Enable/Disable.
Set to Disable, FX EMULATION MENU of User Menu is not
displayed.
Sets Category ESC/P EMULATION MENU Enable/Disable.
Set to Disable, ESC/P EMULATION MENU of User Menu is not
displayed. (Displayed only for Domestic market)
Sets Category PARALLEL MENU Enable/Disable.
Set to Disable, Category PARALLEL MENU of User Menu is not
displayed.
Sets Category RS232C MENU Enable/Disable.
Set to Disable, Category RS232C MENU of User Menu is not
displayed. Displayed only if RS232C is intalled.
Sets Category USB MENU Enable/Disable.
Set to Disable, Category USB MENU of User Menu is not
displayed.
Sets Category NETWORK MENU Enable/Disable.
Set to Disable, Category NETWORK MENU of User Menu is not
displayed.
Displayed only if a NIC is installed.
Item
ALL
INFO.
PRINT
MEDIA
SYS CONF
PCL MENU
PPR MENU
FX MENU
ESC/P
PARALLEL
RS232C
USB
NETWORK
Value
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
ENABLE
DISABLE
Category
OP MENU

Oki B4350 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	6.2 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Internal memory	16 MB
Processor model	Power PC
Built-in processor	Yes
Maximum internal memory	272 MB
Sound power level (standby)	38 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Paper tray 2 input capacity	500 sheets
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power requirements	230VAC + / - 10%
Compatible operating systems	-Windows 95/98/98 SE/ME/NT4 Workstation/NT4 Server/2000 Workstation/2000 Professional/2000 Server/2000 Advanced Server/XP Professional/XP Home/NT Terminal Server Edition/2000 Terminal Server. -Mac OS 8.6/OS X 10.1.
Display	LCD
Maximum duty cycle	30000 pages per month
Power consumption (printing)	350 W
Power consumption (PowerSave)	13 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	355 x 395 x 200 mm
