Oki Data CONFIDENTIAL

4 Black vertical belts or stripes

• Perform the cleaning page function (see Section 4.2.2).

• Has the problem been solved?

• Yes End.

• No Replace the image drum cartridge.

• Has the problem been solved?

• Yes End

Note:

After replacing the image drum cartridge, reset the drum counter (see User's

Manual).

• Clean the LED lens array of the LED head.

• Has the problem been solved?

• Yes End.

• No Replace the LED head.

• Has the problem been solved?

• Yes End

• No Replace the main control board or high voltage/sensor board.

5 Cyclical defect

Notes:

After replacing the image drum cartridge, reset the drum counter (see User's Manual).

Frequency Remedy

Image drum

Developing roller

Toner supply roller

Charging roller

Cleaning roller

Transfer roller

Heat roller

Back-up roller

Replace or clean the image drum cartridge.

Replace the image drum cartridge.

Replace the transfer roller.

Replace the fusing unit assy.

Replace the back-up roller.

3.71" (94.2mm)

1.86" (47.12mm)

2.96" (75.27mm)

1.21" (30.63mm)

0.93" (23.56mm)

1.95" (49.6mm)

2.44" (62.0mm)

2.73" (69.4mm)
