Oki B4350 - Page 149

1 51112301 Hopping Roller Shaft
2 53342401 Rubber-Hopping Roller
3 51607402 Bearing
4 51228901 One-way Clutch Gear
5 42174301 Roller-Regist
6 51607501 Bearing(Registration)
7 42174201 Roller-Pressure
8 41279501 Holder-Regist L
9 41279601 Holder-Regist R
10 Gear-Pressure
11 41279401 Bearing-Pressure
12 41281201 Spring-Tension
13 41280401 Plate-Contact PA
14 41279301 Bearing-Regist L
15 41279701 Gear-Regist
16 42208501 Roller Assy.-Transfer
17 40438001 Bearing TR
18 41301801 Roller-Back up
19 41584101 Spring Bias
20 41536201 Holder-BU
21 41584201 Bearing-Ball
22 42208601 Lever-Reset L Assy.
23 50805901 Reset Lever R
24 42551201 Arm-Switch
25 50924201 Reset Spring
26 42126101 Idle Gear
27 51229201 Idle Gear
28 51010701 Sensor Plate(Inlet)
29 40771401 Lever-Eject Sensor Assembly
30 41027701 Sensor Wire Assembly
31 42468801 Toner Sensor(Adhesion)
32 51010903 Diselectrification Bar Shaft
33 52203802 Diselectrification Film
34-a 42209201 Heat Assy 110V/120V
34-b 42209202 Heat Assy 230V
35 40772501 Roller Assy.-Eject
42145701 Cover Assy.-Front Beige
42145703 Cover Assy.-Front Black
42145801 Cover Assy.-Stacker Beige
42145802 Cover Assy.-Stacker Black
42129101 Holder-Head Beige
42129102 Holder-Head Black
39 42146701 Film-FG
40 42146501 Spring-Head
41 56639709 FUJI-CARD(24P)
42 42146601 Contact-Head
43 42266803 LED Head Unit-51MXF3
44 42660001 Frame Subassy.-Lower
45 42596601 Damper Oil
46 42657501 Bracket-Motor(Caulking)
47 42352501 Bracket-Sub-M
48 42196001 Motor-Pulse(Main)
49 42196101 Motor-Pulse(Regist)
50 42121701 Gear-M3
51 42121801 Gear-M2
52 42121901 Gear-R2
53 50517201 Washer C
54 53347201 FG Plate OP
36
38
37
NameParts No. RemarksNo.
