Oki B4350 - Page 19

42641101TH Rev.1 19 /
Oki Data CONFIDENTIAL
[Base unit]
Figure 2-3
Paper cassette
Cassette guide (L) Assy
Cassette guide (R) Assy
DC fan assy
Face up stacker assy
Operator panel assy
Power supply/sensor board
(Low voltage)
High voltage /
sensor board
Main control board
Network Interface board
