42641101TH Rev.1 73 /

Oki Data CONFIDENTIAL

8 White vertical belts or streaks

• Are the LED lens dirty?

• Yes Clean the LED lens.

• No Is the contact plate of the transfer roller in proper contact with the high voltage/sensor board

(see Figure 5-5)?

• No Adjust the contact plate to make a proper contact with the high voltage/sensor board.

• Yes Replace the transfer roller.

• Has the problem been solved?

• Yes End

• No Is the tension between the back-up roller (7.52kg) and the surface of back-up roller normal?

•No Replace the back-up roller or bias spring.

• Yes Is the LED head being installed properly (check HEAD connector on the main control board

and PC connector on the LED head)?

• No Install the LED head properly.

• Yes Replace the LED head.

• Has the problem been solved?

• Yes End

• Yes Replace the image drum cartridge.

• Has the problem been solved?

• Yes End

Note:

After replacing the image drum cartridge, reset the drum counter (see User's

Manual).

• No Replace the main control board or high voltage/sensor board.
