• 2NDTRAY Connector Pin Assignment
(To 2nd Tray)
8
7
4
6
1
2
3
4
5
6
7
8
O
O
O
I
C
O
C
O
Signal Function
OPPAP-N
OPSCK-N
OPSD-N
OPSDP-N
OVP
+38V
SG
+5VA
Paper Sensor 1
Clock
Data
OPT send data
Analog Ground
+38V
Logic Ground
+5V
PIN NO. I/O*
5
2
1
3
* I: In
O: Out
C: Common
