42049001TH Rev.1 34 /
Oki Data CONFIDENTIAL
2.2.18 Main Motors / Solenoid / Paper-End Sensor
(1) Remove the left side cover, the right side cover, the rear side cover, the top cover unit and the
feeder unt (see sections 2.2.2 , 2.2.3, 2.2.5, 2.2.9 and 2.2.17).
(2) Remove the print engine controller PWB, the controller PWB and the film [see sections 2.2.7,
2.2.8 and 2.2.12 (3)].
(3) Remove the fan (ID), the frame duct, the fan (Pow L) and the low voltage power unit (see
section 2.2.12).
(4) Remove the plate-heat, the eject assy, the cover-driver, the color-registration assy and the
board-RSM (see section 2.2.14).
(5) Unscrew the two screws 1 to remove the plate-driver 2.
(6) Disengage the latch to remove the cover-hopping 3.
(7) Remove the fan (fuser) and the image drum up/down sensor 4 (see section 2.2.15).
(8) Disengage the latch to remove the gear assy - planet 5, the shaft 6 and the three rollers 7.
(9) Unscrew the two screws 8 to remove the side plate R assy 9.
(10) Remove the two screws 0 and the two E rings A, then remove the plate-outer B, the gear-idle
K C, and Y and C D, and M E.
(11) Unscrew the three screws F to remove the plate-inner G.
(12) Remove the screws H (one screws each motor-ID I) and the connectors, then uninstall the
motors-ID I.
(13) Remove the screw J to remove the gear assy - hopping K.
(14) Remove the screw L to uninstall the solenoid M.
(15) Remove the spring N, disengage the claw and remove the bushing O, the hopping roller shaft
P and the frame-hopping Q.
(16) Detach the paper-end sensor R and the paper-end lever S.
