Oki C9800 Series User Manual

Scan Direction Bands, Voids, or Streaks
There are areas of the image that are extremely light or are missing entirely. The missing
areas form bands that run along the page from the leading edge to the trailing edge in the
direction of paper travel.
Initial Actions:
 Perform Initial Actions from Print Quality Troubleshooting Practices
Areas of the Printer that Apply to Scan Direction Bands, Voids, or Streaks
 Imaging Unit
 Transfer Unit belt
 LED Heads
Troubleshooting Steps Resolution
1. Print the 100% Solid Fill test print. Are the missing bands in the process
direction?
Yes – Go to Step 2.
No - See "Process Direction
Bands, Voids, or Streaks" on
page 27.
2. Are there any obstructions, dirt or debris in the printer’s paper path? Yes – Clean or remove
obstructions.
No - Go to Step 3.
3. Clean the LED Heads with at dry, lint free cloth. Did this fix the problem? Yes – Complete.
No - Go to Step 4.
4. Remove the each Toner Cartridge and check for toner starvation within the
Imaging Unit(s).
Yes – Replace the Toner
Cartridge.
No - Go to Step 5.
5. Swap the LED Head of the problem color with any other LED Head. Print a Solid
Fill Test Pattern. Has the problem moved with the LED Head?
Yes – Replace the defective LED
Head
No - Go to Step 6.
6. Swap the Imaging Unit of the problem color with any other Imaging Unit.
NOTE: Remove the keys before swapping. Print a Solid Fill Test Pattern to check
for defects. Has the problem color moved with the
Imaging Unit?
Yes – Replace the defective
Imaging
Unit.
No - Go to Step 7.
7. Check the Fuser for damage. Yes – Replace the Fuser.
No - Replace the Engine Control
Board
