%Signals for Pin Assignments (Parallel):
Signals for Pin Assignments (Parallel):
Pin # Signal Return Pin # Direction
1 Strobe 19 To Printer
2 Data 1 20 To Printer
3 Data 2 21 To Printer
4 Data 3 22 To Printer
5 Data 4 23 To Printer
6 Data 5 24 To Printer
7 Data 6 25 To Printer
8 Data 7 26 To Printer
9 Data 8 27 To Printer
10 Acknowledge 28 From Printer
11 Busy 29 From Printer
12 Paper end 30 From Printer
13 Select No Return From Printer
14_ Autofeed _ To printer
15 Not used _ _
16 0V No Return Signal Ground
17 Chassis
Ground
No Return Ground
18** +5V* _ From Printer
ML 380 ( 96-02-03 )
