RS232-C Serial Interfacing
To construct a cable for an RS232-C serial configuration, you will need:
DB-25P equivalent 25-pin plug, shell equivalent to DB-C2-J9.
Beldon (or equivalent) shielded cable with twisted pair conductors. Must be UL and CSA approved.
The cable must be shielded.
The printer has a 25-pin DB-25S receptacle.
ML 380 ( 96-02-03 )
