5.3 Diagnosis and Prescription for Each Error Code

5.3.1 Check item

Check item Contents

Sensor check • Checkthesensorinthetestmode.

• Checkthatthereisnodustonthesensor.

• Checkthattheactuatoriscorrectlyoperated.

Connector check • Checkthattheconnectorisnotdisconnected.

• Checkthatthepinsarenotdeformedanddonotcomeoff.

• Disconnectandreconnecttheconnector.

Harness check • Checkiftheharnessesareopencircuited.

Motor check • Checkthemotorinthetestmode.

• Checkthatthereisnoabnormalityinthedrivingsection.

• Checkthatthereisnoabnormalityintheroller.

Board check • Checkiftheboardisshortcircuitedoropencircuited.
