45641001TH Rev.1

4-3 /

Oki Data CONFIDENTIAL

4.1.3 Imagedimensionaladjustmentinthecopy/printer/faxfunction

[1] Reproduction ratio adjustment of primary scanning direction

The reproduction ratio in the primary scanning direction of the printed image can be

adjustedasfollows:

 <AdjustmentMode(05)>

Code Function Remarks

7000 PPC Thelargerthevalueis,thelargerthereproductionratiointhe

primary scanning direction becomes.

(0.1%/step)

Acceptablevalues:0to255(Default:128)

7001 PRT/FAX Thelargerthevalueis,thelargerthereproductionratiointhe

primary scanning direction becomes.

(0.1%/step)

Acceptablevalues:128to255(Default:128)

 Makeatestcopyandcomparetheimageobtainedwiththecurrentsettings;ifnecessary,

makeadjustmentsaccordingtothefollowingprocedure:

Notes:

• Sincethereproductionratiomayvaryduetoexpansionandcontractionofthepaper

immediatelyaftertheimageisprintedout,itisrecommendedtomeasureitsdimension

after at least 3 minutes have passed.

• Thisadjustmentmaycauseimagetroublessuchasmoire,disappearanceorbreaking

of thin lines on the printed image. Therefore check if there is no such image trouble

whileyouareperformingtheadjustment.

(1) Whilepressing[0]and[5]simultaneously,turnthepowerON.

(2) Keyinacodeandpressthe[START]button.

(3) Keyintheadjustmentvalue.(Tocorrectavalue,pressthe[CLEAR]button.)

(4) Pressthe[OK]or[INTERRUPT]buttontostorethevalue.->Theequipmentgoesback

to the ready state.

(5) Makeatestcopyandchecktheimagecopied.Tochecktheprintedimage,turnoffthe

powerandthenbackon,andthenprinttheimage.Iftheimageisnotinthedesired

reproductionratio,repeatsteps(2)to(4).
