Oki MPS5502 - GR-1170 (Caster)

45641001TH Rev.1
2-4 /
Oki Data CONFIDENTIAL
2.1.4 GR-1170 (Caster)
(1) Press the [Power] button on the control panel to shut it down.
(2) Turnthemainpowerswitchoftheequipmentoff.
(3) Disconnect the power cable.
(4) Release the lock.
Fig. 2-8
(5) Remove 2 screws and take off 2 fixing brackets.
Fig. 2-9
(6) Lifttheequipmentupandremovethecaster.
Fig. 2-10
